U660e Manual Repair
U660e Manual Pdf
This manual provides a component and solenoid application. Without written permission of Automatic Transmission Service Group. U660E Tech Guide with links.cdr.
Product Details (Mini CD)The U660-E transmission a front wheel drive 6 speed fully automatic electronically controlled transmission used in Toyota and Lexus vehicles worldwide. The TCM is mounted on the transmission facing the front of the vehicle and plugs directly in to the transmission case connector.
This manual provides a component and solenoid application chart, sprag rotation, an OBD2 Code list, detailed information on the valve body, valve body mapping for circuit tracing as well as a complete set of oil schematics on Mini CD CD will not work on Mac products.
Fluid - A/T: Service and Repair U660E Automatic Transaxle Up to 08/2009 U660E AUTOMATIC TRANSMISSION / TRANSAXLE: AUTOMATIC TRANSAXLE FLUID: ADJUSTMENT 1. PRECAUTION (w/ Air Suspension) NOTICE: Be sure to read Precaution thoroughly before servicing See: Steering and Suspension/Suspension/Service Precautions/Air Suspension System. 2. PRECAUTIONS AND WORK DESCRIPTION (a) The U660E automatic transaxle does not have an oil filler tube and oil level gauge. When adding fluid, add fluid through the refill hole on the transaxle case. The fluid level can be adjusted by draining excess fluid (allowing excess fluid to overflow) through the No. 1 transmission oil filler tube of the oil pan. HINT 'Overflow' indicates the condition under which fluid comes out of the overflow plug hole. (b) Before adjusting the fluid level, add the specified amount of fluid when the engine is cold and warm up the engine to circulate the fluid in the transaxle. Ensure that the fluid temperature is as specified and the engine is idling. 3. WORK FLOW (a) The adjustment should be performed according to the procedures referenced in the work flow below. Service and Repair U660E Automatic Transaxle.
